7282-5577-10
Our part6-AC168 RoHS
| Qty | Unit price | Saving |
|---|---|---|
| 1+ | £4.20 | — |
| 10+ | £3.00 | |
| 100+ | £2.70 |
Complete your connector
Matching terminals, seals and mating parts for this housing.
Terminals 1
Select the plating and wire size for the cavity. Listed terminals are alternatives for this housing.
Seals and plugs 1
Select by wire outside diameter. Plug any unused cavities.
Connectors and housings 1
Related housings in the same family or pin count.
Price isn't everything
This is a genuine YAZAKI YES/YESC 2.8x0.8 part. Cheaper copies sold under the same part number can look identical but may not seal, lock or carry current the same way.
- Manufacturer-made
- Traceable
- Certificate of Conformity on request
Product description
Terminals and seals are included
6 Way Automotive Connector
Family YES/YESC Kaizen Connectors
Type 2.8 x 0.8
Yazaki Part Number 7282-5577-10
Connection Type Wire to Wire
Unsealed/Sealed Sealed
Male/Female Male
Number of Poles 6
Tab Width mm(inches) 2.8(110)
Material Heat-resistance Nylon
Plating -
Colour Dark Gray
Rating -
Mating Part Numbers
7283-5577-10
7283-5926-10
