Bosch 1928406096

336P-CV EMS / Contact Housing 48P / Coding F

Manufacturer Bosch

Product Type Contact Housing

Number of positions 48

Code F

Blade width 1.2mm

Connection System Wire-to-Device

Gender Female

Sealed connection Yes

Primary Locking (Terminal) Lance-locking

Colour black

Body Material PA66

Length 32mm

Width 46.5mm

Height 36.3mm

Temperature range, min. -40°

Temperature range, max. 105°

Terminal Sealing Silicon gel seal

Type of seal (connector) Radial seal

Type of seal (cable) Gel sealing

Type of locking mechanism (connector) Locking lever

Secondary locking Yes

TERMINALS ARE NOT INCLUDED
