TE Connectivity 353027-1 17-Way Female Multilock 040 Connector inc Terminals

TE Connectivity 353027-1 17-Way Female Multilock 040 Connector

The Component: Genuine TE Connectivity Multilock 040 / 040 III High Density Series 17-way unsealed female plug housing. Features a 17-position 3-row straight layout / Compact wire-to-board and wire-to-device application envelope / Premium Natural-White Polybutylene Terephthalate (PBT) structural resin composition / Integrated side lock plate mechanism / Automotive electrical and signal dashboard sub-assembly plug / Component Part Number: 353027-1 / Global Order Reference: 353027-1.

Applications & Fitment: Engineered as a reliable, space-optimized low-voltage signal distribution interface for automotive cabin electronics, instrumentation panels, body control networks, and auxiliary sensory connections. This authentic 17-pin TE Connectivity female receptacle plug is heavily utilized across domestic and international vehicle manufacturing platforms to route low-current signal and microprocessor lines directly to board-mount male headers or inline device enclosures. Molded from premium, impact-resistant Polybutylene Terephthalate (PBT) engineering polymer, the housing features high dimensional stability, low moisture absorption, and absolute insulating resistance across a standard vehicle operating temperature range from -30°C to +105°C. Contact alignment and absolute retention security are maintained through an integrated side-locking plate feature acting as a secondary Terminal Position Assurance (TPA) lock, ensuring individual wires remain seated under typical cockpit acoustics and engine harmonics. The unsealed matrix contains 17 high-density contact cavities designed to house a combination of 0.64mm (.040) nominal micro signal terminals and applicable low-current lines. An essential standard line item for dedicated auto-electrical workshops, custom low-voltage loom builders, and factory wiring repair centers.

Technical Attributes:

- Manufacturer Part Number: 353027-1 (Brand: TE Connectivity / AMP Brand)

- Product Series Taxonomy: Multilock Connector System / .040 High Density III Series

- Total Position Count: 17-Way / 17-Position Female Socket Housing

- Cavity Matrix Layout: 3-Row Straight Structural Grid

- Contact System Size Compatibility: Fitted to accept standard 1.0mm [.039 in] / 0.64mm nominal width .040 Series clean-body female receptacle crimp terminals

- Connector Style: Receptacle Housing for Female Contacts (Free-Hanging, Cable Mount, or Inline Header Interface)

- Connector System Purpose: High-Density Wire-to-Board / Wire-to-Device Configuration

- Ingress Protection Status: Non-Sealed / Unsealed (Cockpit Internal Duty)

- Fastening & Primary Retention: Standard top latch lock supplemented by an integrated secondary side-locking plate

- Base Structural Compound: Premium Polybutylene Terephthalate (PBT) Insulation Compound

- Color Profile: Factory Standard Natural-White

- Terminal Matrix Spacing: 2.50mm [0.098 in] Pitch between contacts with a 4.60mm [0.181 in] Row Spacing

- Certified Operating Boundaries: Continuous performance verified from -30°C minimum up to +105°C maximum

- Associated Mating Components: Connects directly with corresponding Multilock 040 3-row straight or right-angle PCB male board headers matching the 17-position footprint (e.g., matching series headers or inline counterparts)

- Commercial Access: Available as individual loose housing components, trade-pack workshop refill packs, or bulk trade volumes. Progressive B2B tiered wholesale discounts apply instantly inside the cart for wholesale commercial accounts and independent auto-electrical trade professionals.
