YAZAKI 7222-7564-40 · Auto Click™ part 16-AC035
View all Yazaki SWP housings, terminals and seals in the Yazaki Connector Finder →
Matched to this housing. Order any quantity, or request a volume quote for 1,000+.
Select the plating and wire size for the cavity. Listed terminals are alternatives for this housing.
Select by wire outside diameter. Plug any unused cavities.







Terminal and connector position assurance for this housing.
Related housings in the same family or pin count.
Price isn't everything
This is a genuine YAZAKI part. Cheaper copies sold under the same part number can look identical but may not seal, lock or carry current the same way.
16 Way Automotive Connector
Classified Parts Housing
Family SWP Connector
Mating Part Numbers 7123-7564-40
Connection Type Wire to Wire
Unsealed/Sealed Sealed
Male/Female Male Number of Poles 16
Tab size (mm) 1.80
Materials PBT
Size (mm) (Outer shape of parts)
Length 43.10
Width 34.50
Colour LIGHT GRAY
