6181-6481

Terminals and seals are included

10 Way Automotive Connector

We ship Worldwide daily and you can buy online safely using PayPal

We are the UK's largest specialist stockist of Automotive Connectors, and we offer low cost shipping to all Countries, fast and safe.

6181-6481

HV/HVG sealed series

Housing Inline

1.0mm(040)

Sealed/Unsealed sealed

Male/Female M

Way

10

Mating parts 6189-6906(HV/HVG sealed series)

Materials PBT

Color Black

Contact resistance

Initial

5mΩ Max.

after durability tests

10mΩ Max.

Leak current 100μA Max.

Insulation resistance 100MΩ Min.

Seal

Initial

98kPa Min.

after durability tests

49kPa Min.
