TE 1355789-1 10-Way Female MQS Connector Plug (BMW 6909000)

The Component: Genuine TE Connectivity 1355789-1 10-way automotive unsealed female plug housing connector assembly. Micro Quadlok System (MQS) 10-position dual-row socket casing (Black / PBT-GF / Unsealed / 2x5 Grid Layout / Internal Retaining Latch System / Factory Component Cross-Ref: 1355789-1 / BMW Group OE Part Number: 61136909000 / Engineering Production Cast Stamping: 6909000).

Applications & Fitment: Designed as a high-density, low-overhead original equipment (OE) wire-to-device and inline signal connection solution for automotive sub-assemblies. Deployed heavily across modern BMW Group vehicle architectures—including BMW F-Series and G-Series passenger models, Mini, and Rolls-Royce platforms—as well as select VAG (Volkswagen Audi Group) subsystem modules.

This specific 10-pin interface is the definitive factory match for electronic turn signals, ambient cabin interior lighting controllers, steering column multi-function switch links, dashboard instrument cluster feeds, and low-current parking distance control (PDC) sensor module junctions. Positioned inside doors, roof headliners, and trunk panels, it faces repeated mechanical stress during custom retrofit additions, trim upgrades, or accident repair teardowns. It is a frequent auto-electrical replacement item because the thin integrated plastic latching beams become brittle over time and snap easily if extracted without an appropriate release tool, compromising physical mating security.

Technical Attributes:

- Manufacturer Part Number: 1355789-1 / 13557891 (Brand: TE Connectivity / AMP Automotive Class)

- OEM Cross-Reference: BMW 61136909000 / 6909000 (Stamping Code: 6909 000)

- Product Series Taxonomy: Micro Quadlok System (MQS) Interconnect Family

- Configuration: 10-Position / 10-Way Female Plug, Dual-Row 2x5 Matrix Layout

- Connector Style: Receptacle Housing for Female Socket Contacts

- Connection Layout Type: Wire-to-Board or Wire-to-Wire Free-Hanging Subsystem Channel

- Fastening & Locking Architecture: Employs an internal plastic locking interface that securely snaps onto mating male board headers or male inline coupling caps

- Base Structural Compound: Premium Polybutylene Terephthalate Glass-Fiber Reinforced (PBT-GF) engineering polymer

- Color Profile: Factory Solid Black Outer Body Housing

- Environmental Sealing Level: Unsealed / Protected Enclosure Class (For interior cabin or fully shielded dry enclosure installations)

- Circuit Performance Thresholds: Optimized for delicate logic-level sensor paths, dashboard instrumentation, and low-voltage high-speed signal distribution networks

- Low Level Contact Resistance: Engineered to maintain a tightly capped 3mΩ maximum initial electrical path resistance

- Operational Thermal Window: Continuous performance envelope certified for severe thermal cycles from -40°C up to +120°C

- Target Female Terminal Contacts (Not Included): Precision matched to accept standard TE Connectivity MQS Series 0.63mm nominal width female receptacle crimp terminals (e.g., 965906-1, 5-965906-1, or 928999-1)

- Target Wire Gauge Section: Accepts ultra-thin-wall primary vehicle wiring within the 0.22mm² to 0.75mm² boundaries (approx. 24 AWG to 18 AWG equivalent)

- Mating Counterpart Interface: Pairs seamlessly with respective 10-way MQS male PCB-mount headers or 10-position inline male cap housings (such as TE 1-929270-1)

- Commercial Access: Tiered B2B wholesale trade volume pricing breaks apply instantly inside your basket for independent tuning garages, loom remanufacturers, and trade auto-electrical stockists.
