Sumitomo 6180-3241 MT Sealed Series 3-Way Female Plug

The Component: Genuine Sumitomo 6180-3241 3-way automotive sealed connector housing plug. MT Sealed 2.3mm (090) Series 3-position 2-row female socket inline receptacle casing (Natural White / PBT / Sealed / Cable Mount Inline Plug / Mating Tab Width 2.3mm / Component Alias: 61803241).

Applications & Fitment: Designed as a primary factory original equipment (OE) harsh-environment connection solution for low-voltage power and critical signal automotive telemetry. Extensively specified across prominent global Japanese motorcycle and passenger car platforms (including heavy deployment across Yamaha, Suzuki, and Kawasaki wiring grids) as the definitive female plug interface for camshaft position sensors, crank angle sensors, fuel pumps, gear position indicators, and motorcycle side stand switch runs.

Engineered to maintain complete electrical continuity under brutal powertrain harmonic vibration and direct high-pressure road wash. Highly vulnerable to primary external locking arm snapping if pried roughly when brittle from cold ambient cycles, or internal front matrix seal tearing if back-probed using raw, un-profiled workshop multimeter test needles during field electronic troubleshooting.

Technical Attributes:

- Manufacturer Part Number: 6180-3241 (Brand: Sumitomo Wiring Systems / Japan Genuine Class)

- Product Series Taxonomy: MT Sealed Series / 2.3mm (.090 inch) Waterproof Interconnect Group

- Configuration: 3-Position / 3-Way Female Receptacle Housing, 2-Row "T-Type" Configuration Matrix

- Connector Style: Plug Housing for Female Socket Contacts (Inline Shroud Profile)

- Connection Layout Type: Wire-to-Wire or Wire-to-Device Interconnect Channel

- Terminal Seating Sizing: 2.3mm (.090 inch) flat female socket box terminal tracking geometry

- Base Structural Compound: Premium High-Grade Polybutylene Terephthalate (PBT) resin compound

- Color Profile: Factory Solid Natural (White / Uncolored)

- Fastening & Locking Architecture: Integrated robust heavy-duty overhead external mechanical thumb-latch locking mechanism

- Environmental Sealing Level: High-performance watertight, dustproof, and splashproof protection; relies on an internal precision-fitted silicone rubber perimeter radial face seal

- Circuit Performance Thresholds: Low-voltage electrical logic and power infrastructure handling yielding an exceptionally clean initial contact path restriction capped at a 3.0mΩ Maximum baseline layout restriction (10mΩ Maximum post-durability limits)

- Current Leakage Capacity: Rated with a safe continuous threshold profile capping current migration at 100μA Maximum

- Insulation Isolation Efficiency: 100MΩ Minimum isolation grid tracking barrier measured at 500V DC

- Operational Thermal Window: Premium wide-range thermal stability certified for continuous service from -40°C up to +120°C

- Target Female Terminal Contacts (Not Included): Fits standard Sumitomo MT/HD sealed series 2.3mm (090) female box socket crimp terminals, including 0.3-0.5mm² wire sections (such as 8100-1427) or 0.75-1.25mm² larger primary wire paths (such as 8100-1428)

- Associated Rubber Wire Seals (Not Included): Accommodates standard Sumitomo 2.3mm (090) individual wire insulation single-wire seals (such as 7165-0118 or 7165-0119 depending on wire outer diameter limits) to preserve structural waterproof integrity

- Mating Counterpart Housing: Pairs seamlessly inline as the direct female partner to Sumitomo MT sealed series 3-way male pin tab housing blocks, including the 6187-3231 inline cap receptacle
