Kostal 09441382 3-Way Female SLK 2.8 Coding B Connector

The Component: Genuine Kostal high-performance sealed female receptacle connector plug housing. SLK 2.8 Sealed Series taxonomy / 3-position single-row female casing / Mechanical Coding B Profile (Jet Black Housing Shell / Premium Heat-Stabilized PBT / Sealed Waterproof / 1x3 Grid Layout / Female Sensor and Device Plug / Component Variant Alias: 9441382 / Global Order Reference: 09441382).

Applications & Fitment: Engineered as a premium, high-reliability original equipment (OE) wire-to-wire or wire-to-device waterproof connection plug designed explicitly for harsh under-hood environmental conditions and high-vibration engine monitoring systems. This 3-pin female housing is an absolute wiring loom staple across prominent European vehicle platforms—extensively integrated within BMW and Mercedes-Benz engine networks. It is standardly deployed across critical single-row vehicle monitoring runs, most notably serving as the primary factory connector interface for engine oil level sensors (frequently cross-referenced with BMW OE part numbers 12521433915 and 1433915), camshaft position sensors, and select heavy-duty crankshaft monitoring modules. It features an integrated white mechanical secondary side-locking slide rail mechanism (Sidelock) that snaps into place after terminal loading to provide positive terminal position assurance (TPA), alongside an integrated top-mounted thumb latch clip that ensures a secure, low-tolerance interface over the mating device header's retention ramp. Engineered to conform to rigid tier-1 European factory validation guidelines, its internal cavities pair with individual single-wire seals to form an absolute barrier against high-pressure moisture ingress, severe road spray washdowns, salt misting, and hot engine oil vapors. Highly vulnerable to white side-locking rail fracturing or slider derailment if field maintenance technicians attempt to pry the mechanism with un-profiled workshop screwdrivers before releasing the primary safety tracks.

Technical Attributes:

- Manufacturer Part Number: 09441382 / 9441382 (Brand: KOSTAL Kontakt Systeme / Germany Genuine Class)

- Product Series Taxonomy: SLK 2.8 Sealed (SWS) Interconnect Family

- Configuration: 3-Position / 3-Way Female Receptacle Plug, Single-Row 1x3 Layout

- Indexed Polarization: Mechanical Coding B Profile to prevent cross-mating in tight multi-sensor harness fields

- Contact System Terminal Envelope: Custom-engineered to shield high-reliability Kostal SLK 2.8mm flat receptacle female socket terminals

- Connector Style: Receptacle Housing for Female Contacts (Free-Hanging Wire Loom or Direct Device Module Interface)

- Fastening & Locking Architecture: Features an integrated positive locking top-mounted thumb latch lever paired with an explicit white side-loading TPA lock slider

- Environmental Sealing Level: High-performance waterproof and dustproof isolation utilizing a pre-installed inner rubber perimeter interface ring matrix and independent single-wire cavity seals (SWS)

- Base Structural Compound: Premium Heat-Stabilized Polybutylene Terephthalate (PBT) engineering polymer for maximum thermal tracking resistance, rigid dimensional memory, and chemical resistance

- Color Profile: Factory Standard Jet Black housing block with a high-visibility white secondary lock slider

- Circuit Rating Threshold: Form-fitted for standard low-voltage signaling and medium-power sensor networks operating below 32V DC continuous; reference current classification rated up to 10 Amps / 32 Amps depending on loaded terminal choice

- Applicable Wire Cross Section: Supports standard vehicle copper sections ranging from 24 AWG (0.22mm²) minimum up to 14 AWG (2.5mm² / 4.0mm²) maximum depending on terminal specification

- Operational Thermal Window: Severe-duty engine block and oil pan pan layout certified to maintain material elasticity and seal compliance from -40°C up to +125°C

- Target Female Terminal Contacts (Not Included): Precision optimized to accept genuine Kostal SLK 2.8 series female crimp sockets (requires individual cavity single-wire rubber seals such as green 10800472631 or yellow 10800583400 to preserve full IP-rated waterproof isolation)

- Commercial Access: Available as loose individual housing shells or complete trade repair connection kits containing matched terminals and wire seals. Tiered B2B wholesale trade volume pricing breaks apply instantly inside your basket for independent garages, loom remanufacturers, and trade auto-electrical stockists.
