Product Type Features
Connector System : Wire-to-Board, Wire-to-Device
Sealable : Yes
Connector & Contact Terminates To : Printed Circuit Board
Hybrid Header : No
Configuration Features
Number of Positions : 12
Number of Rows : 2
Body Features
Color : Black
Connector Code : B
Contact Features
Pin Diameter : 1.5 mm [ .059 in ]
Interface Plating : Tin (Sn)
Termination Features
Termination Method : Through Hole - Solder
Mechanical Attachment
Mounting Orientation : Horizontal/90°
Housing Features
Centerline (Pitch) : 4.5 mm [ .175 in ]
Dimensions
Width : 35.26 mm [ 1.388 in ]
Profile Height from PCB : 35.26 mm [ 1.388 in ]
Length : 59.21 mm [ 2.331 in ]
Usage Conditions
Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]
Operating Temperature (Max) (°C): 100, 105, 110, 120, 125, 65, 70, 75, 80, 85, 90
Operating Temperature (Max) (°F): 149, 158, 167, 176, 185, 194, 212, 221, 230, 248, 257
Industry Standards
Degree of Protection : IP68
UL Flammability Rating : None
