DT06-12SA-E003

Terminals and seals are Included

12 WAY AUTOMOTIVE CONNECTOR

Connector Style : Housing for female terminals

Connector System : Wire-to-Wire

Sealable : Yes

Hybrid Connector : No

Primary Locking Feature : Integrated in Housing

Strain Relief : Add By Accessory

Configuration Features

Number of Positions : 12

Number of Rows : 2

Body Features

Color : Gray

Connector Code : A

Cable Exit Angle : 180°

Body Material : PA GF

Contact Features

Mating Pin Diameter : 1.5 mm [ .059 in ]

Contact Current Rating (Max) (A): 13

Mechanical Attachment

Mounting Feature : Without

Terminal Position Assurance : No

Polarized : No

Housing Features

Centerline (Pitch) : 4.5 mm [ .175 in ]

Dimensions

Width : 20.83 mm [ .82 in ]

Height : 32.21 mm [ 1.268 in ]

Length : 40.56 mm [ 1.597 in ]

Usage Conditions

Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]

Operation/Application

Circuit Application : Power & Signal

Industry Standards

Degree of Protection : IP68

UL Flammability Rating : 20mm Flame Test per Standard UL-94
