| Quantity | Unit Price | Saving |
|---|---|---|
| 100+ | £5.10 |
Product Type Features
Connector & Housing Type : Housing for Female Terminals
Connector System : Wire-to-Wire
Sealable : Yes
Hybrid Connector : No
Primary Locking Feature : Integrated in Housing
Connector & Contact Terminates To : Wire & Cable
Configuration Features
Number of Positions : 12
Number of Rows : 2
Blank Cavity Position : 0
Electrical Characteristics
Operating Voltage (VAC): 250
Operating Voltage (VDC): 250
Nominal Voltage Architecture (V): 12, 24, 48
Body Features
Body Material : PA GF
Cable Exit Angle : 180°
Primary Product Colour : Gray
Connector Code : A
Contact Features
Mating Pin Diameter : 1.59 mm [ .063 in ]
Contact Current Rating (Max) (A): 13
