8 WAY AUTOMOTIVE CONNECTOR
Connector Style : Housing for female terminals
Connector System : Wire-to-Wire
Sealable : Yes
Hybrid Connector : No
Primary Locking Feature : Integrated in Housing
Strain Relief : Add By Accessory
Configuration Features
Number of Positions : 8
Number of Rows : 2
Body Features
Color : Gray
Connector Code : A
Cable Exit Angle : 180°
Body Material : PA GF
Contact Features
Mating Pin Diameter : 1.5 mm [ .059 in ]
Contact Current Rating (Max) (A): 13
Mechanical Attachment
Mounting Feature : Without
Terminal Position Assurance : No
Polarized : No
Housing Features
Centerline (Pitch) : 4.5 mm [ .175 in ]
Dimensions
Width : 22.15 mm [ .872 in ]
Height : 32.44 mm [ 1.277 in ]
Length : 37.21 mm [ 1.465 in ]
Usage Conditions
Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]
Operation/Application
Circuit Application : Power & Signal
Industry Standards
Degree of Protection : IP68
UL Flammability Rating : 20mm Flame Test per Standard UL-94
