Connector Style : Housing for male terminals
Connector System : Wire-to-Wire
Sealable : Yes
Hybrid Connector : No
Primary Locking Feature : Integrated in Housing
Strain Relief : Add By Accessory
Configuration Features
Number of Positions : 8
Number of Rows : 2
Body Features
Color : Gray
Connector Code : A
Cable Exit Angle : 180°
Body Material : PA GF
Contact Features
Mating Pin Diameter : 1.5 mm [ .059 in ]
Contact Current Rating (Max) (A): 13
Mechanical Attachment
Mounting Feature : Without
Terminal Position Assurance : No
Polarized : Yes
Housing Features
Centerline (Pitch) : 4.5 mm [ .175 in ]
Dimensions
Width : 25.4 mm [ 1 in ]
Height : 47.19 mm [ 1.858 in ]
Length : 36.45 mm [ 1.435 in ]
Usage Conditions
Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F
