  • DT04-08PA-CE02

DT04-08PA-CE02

Terminals and seals are Included



Connector Style : Housing for male terminals

Connector System : Wire-to-Wire

Sealable : Yes

Hybrid Connector : No

Primary Locking Feature : Integrated in Housing

Strain Relief : Add By Accessory

Configuration Features



Number of Positions : 8

Number of Rows : 2

Body Features



Color : Black

Connector Code : A

Cable Exit Angle : 180°

Body Material : PA GF

Contact Features



Mating Pin Diameter : 1.5 mm [ .059 in ]

Contact Current Rating (Max) (A): 13

Mechanical Attachment



Mounting Feature : Without

Terminal Position Assurance : No

Polarized : Yes

Housing Features



Centerline (Pitch) : 4.5 mm [ .175 in ]

Dimensions



Width : 25.4 mm [ 1 in ]

Height : 45.67 mm [ 1.798 in ]

Length : 36.45 mm [ 1.435 in ]

Usage Conditions



Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]


Write a review

Please login or register to review


  • Brands DEUTSCH CONNECTORS DT04-08PA-CE02
  • Auto-Click part number: D-AC003
  • Availability: Out Of Stock
  • RoHS:
  • Ships from: Our UK warehouse
  • Ship to: Worldwide
  • Shipping options: Royal Mail, UPS
  • Payment options: PayPal, Debit/Credit Card, Bank Transfer
  • Online price £3.85
