Product Type Features
Sealable : No
Primary Locking Feature : On the Terminal
Contact Features
Crimp Type : Indent
Typical Current Rating (A): 7.5
Wire Contact Termination Area Plating Material : Gold
Contact Fabrication : Solid
Contact Size : Size 20
Terminal Type : Pin
Mating Pin Diameter : 1.02 mm [ .04 in ]
Interface Plating : Gold (Au)
Termination Features
Termination Method to Wire & Cable : Crimp
Product Terminates To : Wire
Dimensions
Wire Size (AWG): 20
Wire Size (mm²): .52
Wire Size Search (mm²): .5
Wire Size Search (AWG): 20
Usage Conditions
Insulation Option : Uninsulated
Operating Temperature (Max) (°C): 80, 85, 90, 100, 105, 110, 120, 125, 130, 140, 145, 150
Operating Temperature (Max) (°F): 176, 185, 194, 212, 221, 230, 248, 257, 266, 284, 293, 302
Operating Temperature Range : -55 – 150 °C [ -67 – 302 °F ]
Operation/Application
Compatible With Wire Base Material : Copper
