180916 bag of 100

Terminals included

Terminates To : Wire & Cable

Housing Type : Tab Housing

Sealable : No

Insulated : No

Product Type : Terminal Housing

Configuration Features

Number of Positions : 1

Body Features

Housing Color : Natural

Mating Retention : With

Mating Alignment : With

Contact Features

Terminal & Splice Type : Tab

Terminal Orientation : Straight

Mechanical Attachment

Mounting Style : Free Hanging

Mating Retention Type : Latch

Housing Features

Housing Material : Polyamide

Dimensions

Length : 31.1 mm [ 1.22 in ]

Usage Conditions

Operating Temperature Range : -40 – 105 °C [ -40 – 221 °F ]

Industry Standards

UL Flammability Rating : UL 94V-2
