Original Toyota 90980-11653

Toyota 90980-11653 10-Way 090 Series 2.3mm Female Housing

The Component: Genuine Toyota OEM 10-position female socket housing / 090 II & TS Sealed Series 2.3mm waterproof automotive connector plug / Compact 1x10 single-row inline cavity layout / Top push-latch primary locking arm with integrated internal silicone weather seal and secondary terminal locking retainer / Molded from high-grade, heat- and chemical-resistant Polybutylene Terephthalate (PBT) resin / Component Part Number: 90980-11653 / Alternate OEM Identifiers: Toyota 90980-11653 / 9098011653 / Sumitomo 6189-0668 cross / 090 II 10-Pin Female Plug / Japanese 10-Way Sealed Connector / 2.3mm 10-Way Waterproof Housing.

Applications & Fitment: High-reliability waterproof female electrical connector housing engineered for engine bay, transmission, chassis, and lighting sub-harnesses across Toyota, Lexus, and Scion vehicle platforms. Designed specifically to hold ten 2.3mm (090 series) female socket crimp terminals and individual silicone wire cavity seals on a single-row layout. Mates directly with male connector housing Toyota 90980-11652. Widely specified for engine harness inline pass-throughs, automatic transmission control interfaces, headlight/lighting harness distribution, and junction connections requiring full IP67 weatherproofing integrity. Engineered to withstand continuous engine compartment vibration, severe fluid exposure (oils, transmission fluid, washer fluid), and extreme thermal cycling (-40 to 125 degrees Celsius). Essential stock for auto-electricians, Japanese vehicle specialists, harness repair technicians, and trade distributors.

Technical Attributes:

- OEM Part Number: 90980-11653 / 9098011653 (Manufacturer: Toyota / Sumitomo / Yazaki)

- Product Component Classification: 2.3mm (090 Series) Female Socket Connector Housing Device

- Connector Family Series: Toyota 090 II / TS Sealed Series

- Connection Type: Wire-to-Wire / Wire-to-Device Inline Female Receptacle

- Total Position Count: 10-Way / 10-Pin Female Plug

- Cavity Layout Matrix: 1 Row x 10 Columns Inline Configuration Profile

- Compatible Terminal Blade Width: 2.30 mm (090 Class) Female Socket Contacts

- Terminal System Compatibility: Accepts 090 II / TS series female socket crimp terminals (e.g., Sumitomo 8100-1429, Yazaki 7116-4020 series) and individual silicone wire seals (e.g., 7165-0118 / 7158-3030 series)

- Directly Mating Part Number: Toyota 90980-11652 (090 Series 10-Way Male Housing)

- Ingress Protection Status: Weatherproof / Waterproof Fully Sealable (IP67 Rated)

- Structural Material Base: Premium Grade Polybutylene Terephthalate (PBT)

- Color Profile: Factory Solid Black Body

- Operating Temperature Limit: -40 to 125 degrees Celsius

- Commercial Procurement Status: Provided as an individual unpopulated 10-way female housing assembly with internal seal. Crimp terminals, wire seals, and mating male connector assemblies (90980-11652) are sold separately. Multi-tier trade volume discounts apply automatically at checkout.
