Genuine Yazaki 7283-6454-40. 6-Way female unsealed automotive connector plug housing (Light Grey / Neutral).

Terminals are included

Series Taxonomy: Yazaki YESC Kaizen 1.5 Series. A highly advanced, high-density Japanese automotive interconnect platform engineered by Yazaki to streamline space-critical cabin signaling and electronic module loops.

Terminal Interface: 6-pin dual-row cavity matrix configuration designed explicitly to house compact 1.5mm wide female receptacle socket contacts.

Locking and Sealing Security: Formed as an unsealed structural housing, precision-engineered for protected cabin zones or interior liftgate wire paths. Mating alignment is driven by asymmetric polarization tracks and a top-mounted mechanical click latch, while internal terminal stability relies on an integrated front retainer track (such as front holder part number 7158-5981) acting as the terminal position assurance check.

Mating Complement: Connects wire-to-wire or wire-to-device by mating directly onto the corresponding 6-way male counterpart housing under Yazaki part number 7282-6454-40.

Common Applications: Extensively specified across prominent global vehicle networks, cross-referencing with Ford engineering code 4S7T-14489V-GA, Volvo reference 30669636, and Tesla designation X340 on platforms like the Model Y. Most frequently deployed as the primary factory harness interface for high-definition rear-view backup cameras, tailgate locking latches, and mirror glass memory telemetry clusters. Highly prone to thumb-latch fracture or internal terminal lane damage if forced open using improper panel tools during tailgate trim teardowns.

Yazaki 7283-6454-40 YESC Kaizen 1.5 Series 6-Way Unsealed Female Camera Plug Housing

Eliminate video feed flickering, re-establish flawless low-voltage sensor signaling, and execute factory-grade electronic repairs inside your vehicle's tailgate harness with the genuine Yazaki 7283-6454-40 6-way female unsealed connector plug housing. Precision-engineered to strict Tier-1 original equipment automotive specifications by Yazaki, this 6-pin 1.5mm female interconnect block is a critical repair piece for servicing modern electronic component grids. Designed with a tight dual-row cavity matrix optimized around the YESC Kaizen 1.5 terminal footprint, it provides a highly stable, zero-resistance connection path that safely manages low-voltage digital signal telemetry up to 15A without risking localized resistance spikes.

The 7283-6454-40 carrier block is injection-molded from a premium, heat-stabilized Polybutylene Terephthalate (PBT) compound finished in a neutral factory light grey tone, guaranteeing exceptional impact resistance, high dimensional accuracy, and complete immunity to cracking under prolonged structural vibrations. Its sleek, compact exterior is engineered to glide cleanly through tight vehicle body cavities and internal tailgate panel channels without snagging delicate factory wrap lines. The heavy-duty integrated top mechanical lock provides positive retention, snapping firmly past the mating male tab housing to combat aggressive chassis vibrations. This authentic component allows auto-electrical trade masters, retrofitting technicians, and diagnostic engineers to complete clean, professional factory pigtail restorations.

Engineering Specifications and Technical Attributes:

- Manufacturer Part Number: 7283-6454-40 (Brand: Yazaki / Japan)

- Configuration: 6-Way Female Receptacle Housing, Dual-Row Inline Contact Matrix

- Product Series Taxonomy: YESC Kaizen 1.5mm Unsealed System Class

- Contact Interface Size: Fits standard 1.5mm wide female socket terminals (e.g., 7116-4100-02, 7116-6315-02)

- Secondary Retention Matching: Accepts front-loading terminal retainer block 7158-5981

- Maximum Current Rating Reference: Rated up to 15 Amperes (Amps) nominal current ceiling

- Locking Security: Integrated heavy-duty top mechanical thumb-latch click lock

- Ford OEM Engineering Cross-Reference: 4S7T-14489V-GA

- Volvo OEM Alternate Part Number Cross-Reference: 30669636

- Tesla Vehicle Harness Designation Code: X340 Connectivity Block

- Commercial Access: Tiered B2B wholesale trade volume pricing breaks apply instantly inside your basket for independent tuning garages, fleet service hubs, and trade auto-electrical stockists.

Family YES/YESC Kaizen Connectors

Type 1.5 X 0.8

Yazaki Part Number 7283-6454-40

Connection Type Wire to Wire

Wire to Device

Unsealed/Sealed Unsealed

Male/Female Female

Number of Poles 6

Tab Width mm (inches) 1.5 (060)

Material PBT

Plating -

Color Light Gray

Rating -

Mating Part Numbers 7282-6454-40 & 7282-5944-40

Product Specification

Allowable Current(Ref.) 15A(Ref)

Low Level Contact Resistance 10milli ohm Max.(Initial)

Insulation Resistance 20Megohm Min.(at 500VDC)

Withstanding Voltage 1000V AC (1min.)

Temperature Range*9 -40 to 100deg.C
