Yazaki 7283-5541-30 3-Way Female YES/YESC Kaizen 1.5mm Connector

The Component: Genuine Yazaki high-performance sealed female receptacle connector plug housing. YES/YESC Kaizen Series taxonomy / 3-position single-row female casing / Standard Coded Keying Profile (Dark Gray Housing Shell / Premium Heat-Stabilized PBT / Sealed Waterproof / 1x3 Grid Layout / Female Inline Harness and Sensor Plug / Component Variant Alias: 7283-5541-30 / Global Order Reference: 7283554130).

Applications & Fitment: Engineered as a premium, high-reliability original equipment (OE) wire-to-wire or wire-to-device waterproof connection plug designed explicitly for compact, high-vibration automotive powertrain environments and chassis sensor networks. This 3-pin female housing is an absolute wiring loom staple across prominent international passenger vehicle networks—heavily integrated inside Japanese and global automotive electrical architectures. It is standardly deployed across critical vehicle sub-assemblies including camshaft position sensors, variable valve timing (VVT) solenoids, electronic throttle controls, and localized low-current engine management triggers. It features an integrated high-stiffness mechanical top-mounted locking latch mechanism that seats cleanly over the mating male shroud's retention ramp, establishing an absolute, low-tolerance interface hold resilient to continuous engine thermal expansion and extreme multi-axis structural harmonics. Engineered to conform to rigid tier-1 factory validation guidelines, its internal cavities pair with advanced front holder locks and individual single-wire seals to ensure absolute terminal position assurance (TPA) and a robust barrier against high-pressure moisture ingress, road salt spray, engine bay dirt, and hot oil misting. Highly vulnerable to internal lance wall deformation or locking latch fracture if field service technicians attempt forced terminal extraction with un-profiled metal workshop picks rather than calibrated extraction tools.

Technical Attributes:

- Manufacturer Part Number: 7283-5541-30 / 7283554130 (Brand: Yazaki / Japan Genuine Class)

- Product Series Taxonomy: YES/YESC Kaizen Connector 1.5X0.8 / 1.5(060) Sealed Series Interconnect Family

- Configuration: 3-Position / 3-Way Female Receptacle Plug, Single-Row 1x3 Linear Layout

- Contact System Terminal Envelope: Custom-engineered to shield high-reliability 1.5mm nominal blade width YES/YESC Kaizen series female socket terminals (060 classification)

- Connector Style: Receptacle Housing for Female Contacts (Free-Hanging Wire Loom or Direct Device Module Interface)

- Fastening & Locking Architecture: Features an integrated positive locking top-mounted thumb latch lever paired with secondary inner terminal alignment front spacer tracking

- Environmental Sealing Level: High-performance waterproof and dustproof isolation utilizing a pre-installed inner rubber perimeter interface ring matrix and independent wire seals

- Physical Footprint Dimensions: 33.45mm Overall Length x 28.50mm Outer Base Width x 26.25mm Overall Height structural layout

- Base Structural Compound: Premium Heat-Stabilized Polybutylene Terephthalate (PBT) engineering polymer for maximum thermal tracking resistance, rigid dimensional memory, and chemical toughness

- Color Profile: Factory Standard Dark Gray housing assembly block

- Circuit Rating Threshold: Form-fitted for standard low-voltage signaling and micro-power power distribution networks operating below 32V DC continuous

- Operational Thermal Window: Severe-duty engine block and chassis layout certified to maintain material elasticity and seal compliance from -40°C up to +125°C

- Target Female Terminal Contacts (Not Included): Precision optimized to accept genuine Yazaki YES/YESC Kaizen 1.5mm (.060) series female crimp sockets (including terminal variants such as part number 7116-4102-02; requires individual cavity single-wire rubber seals like red part number 7158-3030-50 to preserve full IP-rated waterproof isolation)

- Mating Counterpart Interface: Pairs seamlessly inline inside wire-to-wire looms as the direct female partner to matching 3-way male Yazaki YES/YESC Kaizen sealed series connector part number 7282-5541-30

- Commercial Access: Available as loose individual housing shells or convenient trade repair connection kits containing matched terminals and wire seals. Tiered B2B wholesale trade volume pricing breaks apply instantly inside your basket for independent garages, loom remanufacturers, and trade auto-electrical stockists.
