Yazaki 7283-7929 2-Way Female Connector Housing  090II Sealed

The Component: Genuine Yazaki 7283-7929 2-way female connector housing. 2.3II (090II) Sealed Interconnect taxonomy / OEM-Spec Black PBT thermoplastic housing / High-precision 2-circuit interface / Industry-standard locking lever and tactile positive-lock mechanism / Component Variant Alias: 72837929 / Global Order Reference: 7283-7929 / Yazaki Component Class: Sealed Female Receptacle Housing for 090II Series Waterproof Automotive Electrical Systems.

Applications & Fitment: Engineered as a primary original equipment (OE) specification sealed interconnect solution, explicitly designed for secure wire-to-wire or wire-to-device connectivity in high-vibration, high-moisture automotive environments. This 2-way black female housing is a critical staple for harness manufacturers, custom automotive loom builders, and professional electrical repair shops. It is widely utilized across Japanese vehicle platforms—most extensively integrated within Toyota, Honda, and Nissan factory wiring harnesses—for critical sensor nodes, fuel injectors, ignition coils, and auxiliary lighting assemblies.

The housing features a reinforced latching geometry that provides an audible, positive "click" upon mating, ensuring long-term connection integrity under severe multi-axis vibration and continuous thermal cycling. Built to meet stringent Tier-1 automotive manufacturing standards, the housing body is resistant to engine oil, gasoline, diesel, and brake fluid, making it the ideal choice for under-hood and chassis-mounted routing. It serves as a drop-in replacement or factory-standard component for professional harness remanufacturing and is compatible with industry-standard 090II series sealed male tabs and individual wire seals (SWS).

Technical Attributes:

• Manufacturer Part Number: 7283-7929 / 72837929 (Brand: Yazaki / Japan Genuine Component Class)

• Product Series Taxonomy: 2.3II (090II) Series Sealed Automotive Interconnect Family

• Component Type: Sealed Female Receptacle Housing / 2-Way Connector Body

• Housing Material: High-Performance Glass-Filled Polybutylene Terephthalate (PBT) for superior thermal stability and structural rigidity

• Color Profile: Industrial Standard Automotive Black

• Circuit Count: 2-Way (Dual Circuit)

• Locking Mechanism: Integrated Positive-Lock Latch with Secondary Terminal Positioning Assurance (TPA) readiness

• Environmental Sealing Level: Certified for splashproof, dustproof, and high-pressure washdown isolation when properly mated with appropriate wire seals (SWS) and matched male housings

• Operational Thermal Window: Severe-duty engine block, chassis route, and wheel-well layout certified to maintain structural integrity and sealing compliance across a performance spectrum from -40°C up to +125°C

• Terminal Compatibility: Engineered for use with Yazaki 090II series female terminals (typically requiring 0.50mm² – 1.25mm² wire capacity depending on terminal choice)

• Assembly Recommendation: Requires proper individual wire seals (SWS) pre-installed on wires before terminal crimping to maintain IP-rated sealing performance; TPA (Terminal Position Assurance) should be engaged after terminal insertion to ensure full locking

• Commercial Access: Available as loose individual housings for localized repairs, convenient workshop stock-kits, or high-volume master production batch runs. Tiered B2B wholesale trade pricing breaks apply automatically at checkout for OEMs, harness manufacturers, and trade auto-electrical stockists. RoHS and REACH compliant for all global manufacturing standards.
