Sumitomo 6189-7073 (Toyota 90980-12572) 2-Way Female 025 Connector Housing

The Component: Genuine Sumitomo Wiring Systems TS Sealed Series 2-way female plug connector housing / Direct Cross-Reference: Toyota OEM Part Number 90980-12572 / Features an ultra-compact 2-position single-row layout configuration / 0.64mm (025) micro sealed terminal socket footprint / Built-in front alignment locking plate serving as terminal position assurance (TPA) / Premium heat-stabilized Dark Gray Polyamide composite plug body / Weatherproof inline sensor-to-harness socket connection / Component Part Number: 6189-7073 / Toyota Order Reference: 9098012572.

Applications & Fitment: Engineered to establish an exceptionally precise, low-profile, and completely weatherproof electrical link within dense automotive engine architectures where space is highly constrained. This authentic Sumitomo 2-pin female plug (alternatively cataloged under Toyota genuine reference 90980-12572) is a widespread factory standard across multiple generations of Toyota, Lexus, and Scion vehicle wiring looms. Utilizing an ultra-compact micro 0.64mm terminal profile arranged in a straight 1x2 configuration, it is explicitly specified to interface with low-current under-bonnet automotive components—most notably factory windshield washer pump motors, exterior ambient air temperature sensors, variable valve timing (VVT) solenoid actuators, and select automotive horn assemblies.

Molded from premium, impact-resistant Polyamide nylon, the heavy-duty plug shell maintains long-term structural integrity and robust latch-arm spring tension under extreme engine bay thermal cycles. The housing features an integrated internal front alignment mask that acts as a secure terminal lock barrier, preventing terminal backing forces from displacing the electrical connection. Complete environmental isolation against oil, chemical solvents, road salt, and high-pressure water spray is achieved via an internal silicone perimeter seal combined with individual 0.64mm single-wire seals (SWS). Highly favored by professional motorsport loom builders, diagnostic auto-electricians, and custom automotive wiring harness specialists demanding factory-correct connector replacements.

Technical Attributes:

- Manufacturer Part Number: 6189-7073 (Brand: Sumitomo Wiring Systems, Ltd.)

- Interchangeable OEM Cross-Reference: Toyota 90980-12572 / 9098012572

- Product Series Taxonomy: TS Sealed Series / 0.64mm (025) Interconnection System

- Total Position Count: 2-Way / 2-Position Female Plug Housing

- Cavity Layout Matrix: Single-Row 1x2 Grid Configuration

- Contact System Size Compatibility: Form-fitted to house 0.64mm (025) series female terminal sockets (e.g., matching Sumitomo TS Sealed female terminals: 8240-0336, 8100-3455)

- Connector Style: Plug Housing for Female Contacts (Free-Hanging Inline or Sensor Component Interface)

- Ingress Protection Status: Weatherproof / Sealed (Equipped with an internal perimeter interface seal; requires 0.64mm single-wire seals to isolate individual wire circuits)

- Primary Fastening Architecture: Integrated top-mounted mechanical thumb-latch arm that clicks rigidly over the mating male component retention ramp

- Base Structural Compound: Premium Heat-Stabilized Polyamide (Nylon) Polymer

- Color Profile: Factory Standard Dark Gray housing casing

- Mating Counterpart Reference: Connects flawlessly with corresponding 2-way male components or factory sensors built around the matching 0.64mm TS system profile (Mating male housing reference: 6188-4797)

- Commercial Access: Available as loose individual component bodies, complete field service repair kit packages (with 0.64mm terminal sockets and seals), or trade volume bulk allocations. Tiered B2B trade volume discounts apply instantly inside the cart for volume trade accounts and auto-electrical stockists.
