Sumitomo 6189-7020 2-Way Female TS 025 Sealed Connector Housing
Our part2-AC066 RoHS| Qty | Unit price | Saving |
|---|---|---|
| 1+ | £2.90 | — |
| 10+ | £2.00 | |
| 100+ | £1.35 |
Complete your connector
Matching terminals, seals and mating parts for this housing.
Terminals 2
Select the plating and wire size for the cavity. Listed terminals are alternatives for this housing.
Seals and plugs 1
Select by wire outside diameter. Plug any unused cavities.
Price isn't everything
This is a genuine SUMITOMO TS 0.64 part. Cheaper copies sold under the same part number can look identical but may not seal, lock or carry current the same way.
- Manufacturer-made
- Traceable
- Certificate of Conformity on request
Product description
The Component: Genuine Sumitomo Electric OEM 2-position female socket housing / Premium TS 025 (0.64mm) Series waterproof automotive connector plug / Compact 1x2 single-row inline cavity layout / Top latching clip mechanism with integrated secondary terminal locking retainer / Internal perimeter silicone weather seal / Molded from heat-, chemical-, and impact-resistant PBT resin / Component Part Number: 6189-7020 / Alternate OEM Identifiers: 61897020 / Sumitomo 6189-7020 / TS 025 2-Way Female Black / Japanese Vehicle Sensor & ABS Plug.
Applications & Fitment: High-reliability waterproof female electrical connector housing engineered for micro-signal and sensor sub-harnesses across Japanese OEM vehicle platforms (Toyota, Lexus, Honda, Nissan, Mazda, Subaru). Designed specifically for two 0.64mm (.025 inch) female socket terminals and individual wire seals. Widely specified for ABS wheel speed sensors, ambient air temperature sensors, windscreen washer pumps, parking assistance sensors, and engine bay sub-harnesses requiring full IP67 weatherproofing integrity. Engineered to withstand continuous engine vibration, heavy road splash, fluid exposure, and severe thermal cycling (-40 to 125 degrees Celsius). Essential stock for auto-electricians, Japanese vehicle specialists, wire harness repair technicians, and automotive trade distributors.
Technical Attributes:
- OEM Part Number: 6189-7020 / 61897020 (Manufacturer: Sumitomo Wiring Systems)
- Product Component Classification: 0.64mm (025) Female Socket Connector Housing Device
- Connector Family Series: Sumitomo TS Sealed Series (025 System)
- Total Position Count: 2-Way / 2-Pin Female Plug
- Cavity Layout Matrix: 1 Row x 2 Columns Inline Configuration Profile
- Compatible Terminal Blade Width: 0.64 mm (.025 Terminal System)
- Terminal System Compatibility: Accepts Sumitomo TS 0.64mm (025) female crimp socket contacts and individual cable wire seals
- Ingress Protection Status: Weatherproof / Waterproof Fully Sealable (IP67 Class equivalent)
- Structural Material Base: Premium Heat-Stabilized Polybutylene Terephthalate (PBT)
- Color Profile: Factory Solid Black Body
- Operating Temperature Limit: -40 to 125 degrees Celsius
- Commercial Procurement Status: Provided as an individual unpopulated 2-way female housing assembly. Female socket crimp contacts, individual wire seals, and mating male connector housing assemblies are sold separately. Multi-tier trade volume discounts apply automatically at checkout.
