184042-1

Includes terminals and seals

Connector Style : Housing for female terminals

Connector System : Wire-to-Board, Wire-to-Device, Wire-to-Wire

Sealable : Yes

Hybrid Connector : No

Primary Locking Feature : Integrated in Housing

Strain Relief : No

Configuration Features

Number of Positions : 1

Number of Rows : 1

Electrical Characteristics

Nominal Voltage Architecture (V): 12, 24, 42, 48, 80, 90, 125

Operating Voltage (VAC): 125

Operating Voltage (VDC): 125

Body Features

Color : Black

Cable Exit Angle : 180°

Body Material : PBT GF

Mechanical Attachment

Mounting Feature : Without

Terminal Position Assurance : No

Polarized : No

Housing Features

Centerline (Pitch) : 5 mm [ .197 in ]

Dimensions

Width : 24.05 mm [ .947 in ]

Height : 27.6 mm [ 1.09 in ]

Length : 17.3 mm [ .68 in ]
