1-1703818-1

Terminals and seals are included

4 Way Automotive Connector

Product Type Features

Connector Style : Housing for male terminals

Connector System : Wire-to-Wire

Sealable : Yes

Hybrid Connector : No

Primary Locking Feature : On the Terminal

Strain Relief : Add By Accessory

Row-to-Row Spacing : 6.45 mm [ .254 in ]

Configuration Features

Number of Positions : 4

Number of Rows : 2

Electrical Characteristics

Nominal Voltage Architecture (V): 12, 24, 42, 60

Operating Voltage (VDC): 60

Body Features

Color : Black

Cable Exit Angle : 180°, 90°

Body Material : PBT GF

Contact Features

Mating Tab Width : 2.8 mm [ .11 in ]

Mechanical Attachment

Mounting Feature : Without

Terminal Position Assurance : Yes

Polarized : Yes

Housing Features

Centerline (Pitch) : 6 mm [ .236 in ]

Dimensions

Width : 48.1 mm [ 1.8937 in ]

Height : 27 mm [ 1.062 in ]

Length : 29.1 mm [ 1.1456 in ]
